Innodisk iCF 9000 8GB

Product Description

The iCF 9000 is a low-profile, high-capacity solid-state flash memory solution designed to replace traditional rotating disk drives.The iCF 9000 works reliably as an embedded data storage system for mobile computing and industrial applications. Extremely lightweight, the iCF 9000 delivers a superior data transfer rate of sequential read and write of up to 100MB/s and 95MB/s respectively.

Model Name: iCF 9000 Wide Temp
Interface: PATA
Type: Standard
Flash Type: SLC
Connector: 50pin CF connector

Max. Channels: 4
Sequential R/W (MB/sec, max.): 100/95
Max. Power consumption: 1.05W(5V x 210mA)/0.69W(3.3V x 210mA)
H/W Write Protect: Yes
ATA Security: Yes
S.M.A.R.T.: Yes

Vibration: 20G@7~2000Hz
Shock: 1500G@0.5ms
MTBF: 3 million hours

torage Temperature: -55⁰C ~ +95⁰C
Operation Temperature: Standard Grade: 0⁰C ~ +70⁰C
Industrial Grade. OP: -40⁰C ~ +85⁰C
