Product Description
2GB Industrial Compact Flash4000
Speed up your system with an additional memory support that can connect to your mini ITX’s IDE slot.
The high capacity ICF compact flash memory storage is well suited for solid-state mass storage applications offering new and expanded functionality while enabling cost-effective designs.
It is designed to replace a conventional rotating disk drive, and can be plugged into a standard CF slot commonly found in desktop or portable PC systems.
Made especially for industrial work place – as they feature extremely lightweight, reliable, low-profile form factor.
– Interface: 50 pin Compact Flash Type1
– PCMCIA v2.1 and PC Card v2.1 ATA compatible
– Mechanical Shock Duration 10ms.
– Vibration support
– High reliability with 4 bit ECC (Error Correction Code) function.
– Mean Time between Failures (MTBF) > 3,000,000 hours.
– R/W endurance 2,000,000 Times.
– Minimum 10,000 insertions.
– Data Transfer Rate:
Read: 20 Mbytes/sec
Write: 12 Mbytes/sec
– DC Input Voltage: +3.3V/+5V Single power supply operation
– Power Consumption: 150mA (Max)
– Operating Temp: -10 Degrees ~ +70 Degrees Celsius
– Humidity: 10%-95% non condensing
– Size: 42.8 x 36.40 x 3.3 mm (WxLxH)
